LBV-3-U16-0001-M : Stauff Multi-Way Diverter Ball Valve, L-Bore, 90 Degree Action, #16 SAE (1"), Carbon Steel, 4500psi, 3-Way
Roll over image to zoom in Click on image to zoom
LBV-3-U16-0001-M : Stauff Multi-Way Diverter Ball Valve, L-Bore, 90 Degree Action, #16 SAE (1"), Carbon Steel, 4500psi, 3-Way

LBV-3-U16-0001-M : Stauff Multi-Way Diverter Ball Valve, L-Bore, 90 Degree Action, #16 SAE (1"), Carbon Steel, 4500psi, 3-Way

Save $457.23
StauffSKU: 3404001721
3-5 Days
Price:
$1,526.99 $1,984.22

Product Details

Data Sheet Download Datasheet
Usually Ships Within 3-5 Days
Factory Location Canton, Michigan
Port Size #16 SAE (1")
O Ring Seals Viton
Pressure Rating 4500
Body Material Carbon Steel
Ball Seal Delrin
Ball Pattern L-Bore, 90-Degree Action
Ball Valve Pressure Range Medium Pressure (1000 to 4999psi)
Flow Style Three-Way
Country of Manufacture Germany
Weight 18.7
Ball Valve Type Standard

Description

Stauff's three-way high pressure block body ball valves are designed for use as three-way selectors for hydraulic applications. This valve is a block body design ideal for inline assembly, has a trunnion style ball, and is supplied with a lever.
