Anchor Fluid PowerSKU: NN1-1
5 Days
Price:
$139.99

Product Details

Data Sheet Download Datasheet
Usually Ships Within 5 Days
Factory Location Cincinnati, Ohio and Houston, Texas
Connection Size 1" NPT
Material Carbon Steel
Panel Mount Option No Panel Mount Nut
Adjustment Type Knob Adjustment
Flow Rating 40
Pressure Rating 5700
Country of Manufacture China
Height 1.77
Length 4
Width 3.93
Weight 3.2

Description

The Anchor Needle valves have a graduated knob and spindle for accurate flow control, and a set screw allows this valve to be locked into position. These valves are carbon steel with zinc chromate plating, and are RoHS Compliant. They come with Buna seals, and PTFE Stem packing. These Anchor Flow Control valves are for control of flow only, and are not to be used as isolation or shut off valves.
