Product Details
| Data Sheet | Download Datasheet |
|---|---|
| Usually Ships Within | 3-5 Days if in Factory Stock, 6-8 Weeks if not in Factory Stock |
| Factory Stock | 0 |
| Factory Location | Bowling Green, Ohio |
| Solid Model | Click here to download |
| Valve Type | Modular (Stacking) Valve |
| Valve Interface | D03 (NG6) |
| Flow Rating | 16 |
| Pressure Rating | 4600 |
| Check Valve Position | Check Valve in Line A |
| Cracking Pressure | 43.5 |
| Check Valve Type | Pilot-Operated |
| Country of Manufacture | Czech Republic |
| Height | 1.77 |
| Length | 4.13 |
| Width | 1.57 |
| Weight | 1.76 |
Description
The Argo-Hytos 2RJV1-06 is a pilot to open check valve, with a sandwich plate design for use in vertical valve stacking assemblies. The valve allows flow to pass from Port A(B)1 to A(B)2 while normally closing flow from A(B)2 to A(B)1 with load. When pressure is applied at pilot port, flow passes from 2 to 1. Three pilot ratio options are available. The check valve is spring closed to secure the holding position in static conditions without load.
