15BEX5L5G : DP Winch, 15,000lb Bare Drum Pull, Base with Tensioner, Manual Kickout/Spring Engage, CCW, Two Speed, Less than 25GPM, 12VDC, 5.5" Barrel x 13.19" Length x 12.75" Flange
Roll over image to zoom in Click on image to zoom
15BEX5L5G : DP Winch, 15,000lb Bare Drum Pull, Base with Tensioner, Manual Kickout/Spring Engage, CCW, Two Speed, Less than 25GPM, 12VDC, 5.5" Barrel x 13.19" Length x 12.75" Flange

15BEX5L5G : DP Winch, 15,000lb Bare Drum Pull, Base with Tensioner, Manual Kickout/Spring Engage, CCW, Two Speed, Less than 25GPM, 12VDC, 5.5" Barrel x 13.19" Length x 12.75" Flange

DP WinchSKU: 15BEX5L5G
6-8 Weeks
Price:
$7,725.54

Product Details

Special Message Base with Tensioner
Data Sheet Download Datasheet
Usually Ships Within 6-8 Weeks
Factory Location Jenks, Oklahoma
Hydraulic Motor Pressure 2500psi
Country of Manufacture United States
Height 12.94
Length 24.19
Width 14.13
Weight 280
Drum Flange Diameter 12.75"
Brake Option N/A
Drum Length 13.19"
Drum Rotation Counterclockwise
Max Bare Drum Line Pull 15,000 lbs
Max Full Drum Line Pull 7,780 lbs
Max Bare Drum Line Speed 38 ft/min
Max Full Drum Line Pull 7,780 lbs
Max Full Drum Line Speed 73 ft/min

Description

With over 75 years of experience and knowledge, TWGÕs planetary winches have the strength to pull you out of trouble. Their planetary winches are commonly used in the Infrastructure, Recovery, Energy & Marine markets custom built for each application. With line pull ratings from 3,000 lbs to 270,000 lbs, they have a winch that can handle your requirements.
