BBV-2-U12-1101-M : Stauff Block Body Ball Valve, #12 SAE (3/4"), 316SS, 6000psi, 2-Way
Roll over image to zoom in Click on image to zoom
BBV-2-U12-1101-M : Stauff Block Body Ball Valve, #12 SAE (3/4"), 316SS, 6000psi, 2-Way

BBV-2-U12-1101-M : Stauff Block Body Ball Valve, #12 SAE (3/4"), 316SS, 6000psi, 2-Way

Save $0.86
StauffSKU: 3404001271
3-5 Days
Price:
$648.99 $649.85

Product Details

Data Sheet Download Datasheet
Usually Ships Within 3-5 Days
Factory Location Canton, Michigan
Port Size #12 SAE (3/4")
O Ring Seals Viton
Pressure Rating 6000
Body Material 316 Stainless Steel
Ball Seal Delrin
Ball Pattern On/Off
Ball Valve Pressure Range High Pressure (5000 to 9999psi)
Flow Style Two-Way
Country of Manufacture Germany
Height 2.94
Length 3.72
Width 1.92
Weight 3.31
Ball Valve Type Standard

Description

Stauff's two-way high-pressure block body ball valve is designed for use as an on/off device for hydraulic applications. The body, ball and stem are available in carbon and stainless steel, and a variety of end connections are available.
