Product Details
| Data Sheet | Download Datasheet |
|---|---|
| Usually Ships Within | Same Day |
| Factory Location | Louisville, Kentucky |
| Port Size | 1/4" NPT |
| Valve Type | Inline |
| Valve Interface | Inline |
| Flow Rating | 422.68 |
| Flow Cv | 1.6 |
| Pressure Rating | 150 |
| Operating Temp Range | -20 to 160 F |
| Valve Series | Nugget 200 |
| Body Material | Aluminum |
| Voltage | No Coil |
| Actuation Type | Air |
| Pressure Range | 4.91 to 150psi |
| Solenoid Electrical Connection | No Connector |
| Flow Scfm | 48 |
| Spool Configuration | 1 Blocked, 2 to 3 in Neutral |
| Positions | 2-Position |
| Way | 5-Way |
| Country of Manufacture | United Kingdom |
Description
The Nugget 200 range of solenoid valves enhance our standard solenoid offering and depending on the range cover the standard functions of 2/2, 3/2, 5/2 and 5/3 in a choice of body materials to suit the application. These valves offer long lasting spool design and a high-flow, compact style in multiple configurations.
