Product Details
| Data Sheet | Download Datasheet |
|---|---|
| Usually Ships Within | Same Day |
| Factory Stock | 8 |
| Factory Location | Louisville, Kentucky |
| Installation & Maintenance Manual | Click here to download |
| Port Size | 1/4" PTF |
| Micron | 5-Micron |
| O Ring Seals | Nitrile rubber |
| Operating Temp Range | -30 to 125 F |
| Body Material | Zinc |
| Relief Option | Relieving |
| Outlet Pressure Range | 5 to 100psi |
| Bonnet | Acetal |
| Flow Scfm | 14 |
| Bowl Material | Polycarbonate |
| Drain Type | Automatic Drain |
| Series | B07 |
| Country of Manufacture | United Kingdom |
| Weight | 0.57 |
Description
The Norgren filter regulator unit is our most popular single compressed air preparation unit. The filter regulator combines accurate pressure adjustment with bulk water (moisture) and particle removal (5 or 40 microns rating) in one unit. This benefits you by saving space and pneumatic connections for the same or improved performance.
| Product SKU | Port Size & Type | Flow SCFM | Relief Option | Drain Type | Outlet Pressure Range | Element Rating | Lead Time | Price |
|---|---|---|---|---|---|---|---|---|
| B07-101-A1KA | 1/8" PTF | 13 | Relieving | Automatic Drain | 5 to 100psi | 5-Micron | 5-7 Days | $98.99 |
| B07-101-M1KA | 1/8" PTF | 13 | Relieving | Manual Drain | 5 to 100psi | 5-Micron | 5-7 Days | $89.47 |
| B07-102-A1KA | 1/8" PTF | 13 | Relieving | Automatic Drain | 5 to 100psi | 5-Micron | 24 Days | $122.72 |
| B07-102-M1KA | 1/8" PTF | 13 | Relieving | Manual Drain | 5 to 100psi | 5-Micron | 5-7 Days | $113.22 |
| B07-103-M1KA | 1/8" PTF | 13 | Non-Relieving | Manual Drain | 5 to 100psi | 5-Micron | 35 Days | $113.53 |
| B07-201-A1EA | 1/4" PTF | 14 | Relieving | Automatic Drain | 5 to 50psi | 5-Micron | 24 Days | $109.07 |
| B07-201-A1KA | 1/4" PTF | 14 | Relieving | Automatic Drain | 5 to 100psi | 5-Micron | 24 Days | $98.99 |
| B07-201-A3KA | 1/4" NPT | 14 | Relieving | Automatic Drain | 5 to 100psi | 40-Micron | 24 Days | $129.62 |
| B07-201-M1EA | 1/4" PTF | 14 | Relieving | Manual Drain | 5 to 50psi | 5-Micron | 24 Days | $103.29 |
| B07-201-M1KA | 1/4" PTF | 14 | Relieving | Manual Drain | 5 to 100psi | 5-Micron | 24 Days | $89.47 |
| B07-202-A1KA | 1/4" PTF | 14 | Relieving | Automatic Drain | 5 to 100psi | 5-Micron | Same Day | $122.72 |
| B07-202-M1KA | 1/4" PTF | 14 | Relieving | Manual Drain | 5 to 100psi | 5-Micron | 5-7 Days | $113.22 |
| B07-205-A1MA | 1/4" NPT | 14 | Relieving | Automatic Drain | 5 to 145psi | 5-Micron | 160 Days | $107.51 |
| B07-205-A1MG | 1/4" ISO G | 14 | Relieving | Automatic Drain | 5 to 145psi | 5-Micron | 5-7 Days | $100.53 |
| B07-205-A3MA | 1/4" NPT | 14 | Relieving | Automatic Drain | 5 to 145psi | 40-Micron | 35 Days | $141.57 |
| B07-205-A3MG | 1/4" ISO G | 14 | Relieving | Automatic Drain | 5 to 145psi | 40-Micron | 24 Days | $100.53 |
| B07-205-M1MA | 1/4" NPT | 14 | Relieving | Manual Drain | 5 to 145psi | 5-Micron | 5-7 Days | $96.34 |
| B07-205-M3MG | 1/4" ISO G | 14 | Relieving | Manual Drain | 5 to 145psi | 40-Micron | 24 Days | $121.35 |
| B07-233-A1KA | 1/4" PTF | 14 | Relieving | Automatic Drain | 5 to 100psi | 5-Micron | 24 Days | $123.16 |
| B07-233-A1KG | 1/4" ISO G | 14 | Relieving | Automatic Drain | 5 to 100psi | 5-Micron | 24 Days | $133.55 |
| B07-233-M1KA | 1/4" PTF | 14 | Relieving | Manual Drain | 5 to 100psi | 5-Micron | 24 Days | $97.53 |
| B07-234-A1KA | 1/4" PTF | 14 | Relieving | Automatic Drain | 5 to 100psi | 5-Micron | Same Day | $130.78 |
| B07-234-M1KA | 1/4" PTF | 14 | Relieving | Manual Drain | 5 to 100psi | 5-Micron | 24 Days | $121.28 |
